Schneider Electric Altivar 61 Variable Frequency Drives VFD

Schneider Electric Altivar 61 Variable Frequency Drives VFD

Details:

Range of product : Altivar 61
product or component type : Variable speed drive
Product specific application : Pumping and ventilation machine
Component name : ATV61
supply number of phases : Single phase and 3 phases
Synchronous motor control profile : Vector control without sensor, standard
Communication port protocol : Modbus CANopen
Type of polarization : No impedance for Modbus
product destination Asynchronous motors Synchronous motors
Nominal switching frequency : 12 kHz
Output frequency : 0.1…599 Hz
Diagnostic : 1 LED (red) for drive voltage
Output voltage : <= power supply voltage
electrical isolation : Between power and control terminals
Protection type
Against exceeding limit speed: drive
Against input phase loss: drive
Break on the control circuit: drive
Input phase breaks: drive
Line supply overvoltage: drive
Line supply undervoltage: drive
Overcurrent between output phases and earth: drive
Overheating protection: drive
Overvoltages on the DC bus: drive
Power removal: drive
Short-circuit between motor phases: drive
Thermal protection: drive
Motor phase break: motor
Power removal: motor
Thermal protection: motor

Weight 3000 g
Dimensions 13 × 23 × 17 cm
Add to wishlist

Description

Altivar 61 Variable Frequency Drives VFD
Drives for variable torque from 1 to 900 HP. For the latest in high-performance drives for pump and fan applications consider using an Altivar Process ATV600 family drive.

Frequency inverters for 3-phase asynchronous motors from 1 to 900 HP, variable torque applications for 575-690V applications. For 230V and 460V drive applications consider the new Altivar Process ATV600 drive family.

Altivar 61 has reached the end of commercialization and a replacement offer has been announced.

The next generation of variable speed drives, Altivar Process is designed to deliver IIoT benefits.
• A smart, connected EcoStruxure-ready drive with built-in intelligence to gather data and share information at the enterprise level.
• Improve operational efficiency, profitability and reduce the total cost of ownership (TCO).
• Offers range from 0.75 kW to 2600 kW in all voltages with easy-to-use and consistent experience for usability, functionality, performance, and flexibility.
variable speed drive Altivar 61, 0.75kW, 1HP, 200 V to 240 V single or thee-phase, IP20 reinforced
