‎L&T (Larsen & Toubro) MNX 300 Contactor 415V AC, 3 Pole

Original price was: 604.81 $.Current price is: 216.87 $.

Details:

MNX Contactor 300A 3P 415V AC AC-3 240V AC Coil 50/60 Hz
MNX power contactor are mainly used in motor feeder ad control system applications.
The range is availabe from 9A to 650A (AC-3) and provides a relaible performance across diverse condition like high ambient temperature, humidity etc.
Standardized accessories and spares are available for the entire range

Dimensions	1.2 × 30.48 × 30.48 cm

Ambient temperature	-20 to 55 degree C
Mechanical Life (No. of operating cycles)	3600 Cy/Hr
Rated impulse withstand voltage (Uimp)	8kV
Rated Insulation Voltage Ui (V)	1000V
Conformance to Standards	IS/IEC 6094741, IEC 6094741
Coil Voltage	240 V AC
Rated operational current at 415V	300A
No. of Poles	3P
Height(mm)	275
Width(mm)	200
Depth(mm)	220
Rated kW	160kW
Rated making capacity	4500A
Coil Operating band %Uc (Pick up)	80 – 110 %
Rated breaking capacity	4000A
Mechanical Life	10 Million
Coil Operating band %Uc (Drop off)	35 – 65 %
Pick up VA consumption	2100VA
Hold on VA consumption	95VA
